I was wondering if I could use a older/newer version of the Thesycon drivers supplied from a different manufacturer than the manufacturer which made my USB device. I have a Musical Fidelity V-Link192 and MF supplies Thesycon driver version 1.61. But for other manufacturers I see higher versions of the Thesycon driver (e.g. Thesycon’s USB audio class driver TUSBAudio targets USB audio devices for professional and semi-professional use and highest quality audiophile HiFi systems. The driver supports devices which are compliant to the USB Audio 2.0 or USB Audio 1.0 device class specification.

Universal USB Development Kit for Windows 10, 8.1, 8 and 7

FeaturesSupported PlatformsDemoPrices

Standard USB devices are normally supported by class drivers included in the Windows operating system. In many cases, a particular USB device cannot be assigned to a device class because it has to fulfill different requirements, or because implementing the class specification in the device firmware is too time-consuming. This makes a custom USB device driver development necessary; a kernel-mode driver which conforms to the Windows Driver Model (WDM).

The development and debugging process of such a kernel-mode driver is very time-consuming, especially if the driver has to support different Windows versions. For this reason, Thesycon has developed the generic USB device driver USBIO. The USBIO software components can be integrated into a final product with product-specific adaptations (e.g. file names, installation paths, copyright messages). The result is a customized version that can be shipped as part of an end user product.

  • Complete USB functionality is supported. The driver is optimized for maximum efficiency. The USBIO driver supports USB 3.0, USB 2.0 and USB 1.1. It supports low, full, high speed and super speed mode.
  • The USBIO driver supports all current 32 bit and 64 bit Windows operating systems.
  • Supports the USB transfer types Control, Interrupt, Bulk, and Isochronous.
  • Provides an interface to USB endpoints (pipes) that is similar to Win32 file I/O interface.
  • Provides full support for asynchronous (overlapped) data transfer operations.
  • Fully support for hot plug and play. It supports Plug&Play notifications for applications.
  • Supports the Windows power management model.
  • Optionally the driver supports advanced USB power management including selective suspend (Windows 10 only)
  • Provides an interface to USB devices that can be used by any Windows 32/64 bit applications. Multiple applications can use the USBIO driver at the same time.
  • Can be used with devices that implement multiple USB configurations. It supports switching between different USB configurations.
  • Can be used with devices that implement multiple USB interfaces. In this case a multi-interface driver is required.
  • Multiple USB devices can be controlled by USBIO at the same time.
  • Provides a Windows programming interface for use in C, C++ and Java programs. A high-level programming interface, the USBIO COM interface, is also available.
  • Several source code examples demonstrate usage of the programming interfaces and show how an application controls a USB device.
  • The driver will be delivered fully customized for licensee’s product.
  • Customization includes USB VID/PID, file names, text strings, etc.
  • Windows 10 version of the driver is signed with Microsoft Attestation signing.
  • Windows 7/8 version of the driver is signed with Thesycon’s code signing certificate.
  • Driver Customization Kit add-on: The Driver Customization Kit enables licensee to customize the driver by themselves.
  • Supported scenarios: first-time installation, driver update, removal of driver software
  • Interactive mode with graphical user interface
  • Silent mode without user interface, enables integration into surrounding software installers
  • Supports popup-free installation

The driver is conform with current WHQL and Hardware Lab Kit (HLK) requirements. To get a WHQL certification, HLK tests must be executed with licensee's device which can be done by licensee or Thesycon. If you are interested in a WHQL certification, please contact Thesycon for a quotation.


Thesycon USB Devices Driver
Windows 10
Windows 8.1
Windows 8
Windows 7


Windows Embedded 8 Standard
Windows Embedded Standard 7 (WES7)
Windows Embedded Enterprise 7
Windows Embedded POSReady 7
Windows Embedded Server


Windows Server 2012 R2
Windows Server 2012
Windows Home Server 2011
Windows Server 2008 R2


Our software is purely designed and implemented by our team in Germany - no outsourcing. Technical support is provided directly by the developers.

Current version: 3.40

Thesycon USB Devices Driver

To receive a free demo, prices or license agreement, please fill out the contact form.

The free evaluation version of the USBIO driver works for an interval of 60 days without any limitation. After that evaluation period has expired, the driver stops working.

NOTE: The driver described on this page is *not for use by end users*. It will not help solve any problems you may experience with a consumer device such as a webcam, camcorder, card reader, external sound card, etc. Thesycon’s device drivers are software components intended to be used by hardware or software manufacturers to create end products.

For each USB device model an official USB vendor ID (VID) is required. Vendor IDs must be unique and will be assigned by the USB Implementers Forum (www.usb.org). Registration fees will be charged.

Thesycon owns a USB vendor ID and provides a subset of product IDs (PID) to licensees of Thesycon drivers.

© 2021 THESYCON

-->

For certain Universal Serial Bus (USB) devices, such as devices that are accessed by only a single application, you can install WinUSB (Winusb.sys) in the device's kernel-mode stack as the USB device's function driver instead of implementing a driver.

This topic contains these sections:

Adapter

Automatic installation of WinUSB without an INF file

As an OEM or independent hardware vendor (IHV), you can build your device so that the Winusb.sys gets installed automatically on Windows 8 and later versions of the operating system. Such a device is called a WinUSB device and does not require you to write a custom INF file that references in-box Winusb.inf.

When you connect a WinUSB device, the system reads device information and loads Winusb.sys automatically.

Thesycon Usb Devices Driver Adapter

Driver

For more information, see WinUSB Device.

Installing WinUSB by specifying the system-provided device class

When you connect your device, you might notice that Windows loads Winusb.sys automatically (if the IHV has defined the device as a WinUSB Device). Otherwise follow these instructions to load the driver:

  1. Plug in your device to the host system.
  2. Open Device Manager and locate the device.
  3. Select and hold (or right-click) the device and select Update driver software... from the context menu.
  4. In the wizard, select Browse my computer for driver software.
  5. Select Let me pick from a list of device drivers on my computer.
  6. From the list of device classes, select Universal Serial Bus devices.
  7. The wizard displays WinUsb Device. Select it to load the driver.

If Universal Serial Bus devices does not appear in the list of device classes, then you need to install the driver by using a custom INF.The preceding procedure does not add a device interface GUID for an app (UWP app or Windows desktop app) to access the device. You must add the GUID manually by following this procedure.

  1. Load the driver as described in the preceding procedure.

  2. Generate a device interface GUID for your device, by using a tool such as guidgen.exe.

  3. Find the registry key for the device under this key:

    HKEY_LOCAL_MACHINESYSTEMCurrentControlSetEnumUSB<VID_vvvv&PID_pppp>

  4. Under the Device Parameters key, add a String registry entry named DeviceInterfaceGUID or a Multi-String entry named DeviceInterfaceGUIDs. Set the value to the GUID you generated in step 2.

  5. Disconnect the device from the system and reconnect it to the same physical port.Note If you change the physical port then you must repeat steps 1 through 4.

Writing a custom INF for WinUSB installation

As part of the driver package, you provide an .inf file that installs Winusb.sys as the function driver for the USB device.

The following example .inf file shows WinUSB installation for most USB devices with some modifications, such as changing USB_Install in section names to an appropriate DDInstall value. You should also change the version, manufacturer, and model sections as necessary. For example, provide an appropriate manufacture's name, the name of your signed catalog file, the correct device class, and the vendor identifier (VID) and product identifier (PID) for the device.

Also notice that the setup class is set to 'USBDevice'. Vendors can use the 'USBDevice' setup class for devices that do not belong to another class and are not USB host controllers or hubs.

If you are installing WinUSB as the function driver for one of the functions in a USB composite device, you must provide the hardware ID that is associated with the function, in the INF. You can obtain the hardware ID for the function from the properties of the devnode in Device Manager. The hardware ID string format is 'USBVID_vvvv&PID_pppp'.

The following INF installs WinUSB as the OSR USB FX2 board's function driver on a x64-based system.

Starting in Windows 10, version 1709, the Windows Driver Kit provides InfVerif.exe that you can use to test a driver INF file to make sure there are no syntax issues and the INF file is universal. We recommened that you provide a universal INF. For more information, see Using a Universal INF File.

Only include a ClassInstall32 section in a device INF file to install a new custom device setup class. INF files for devices in an installed class, whether a system-supplied device setup class or a custom class, must not include a ClassInstall32 section.

Except for device-specific values and several issues that are noted in the following list, you can use these sections and directives to install WinUSB for any USB device. These list items describe the Includes and Directives in the preceding .inf file.

  • USB_Install: The Include and Needs directives in the USB_Install section are required for installing WinUSB. You should not modify these directives.

  • USB_Install.Services: The Include directive in the USB_Install.Services section includes the system-supplied .inf for WinUSB (WinUSB.inf). This .inf file is installed by the WinUSB co-installer if it isn't already on the target system. The Needs directive specifies the section within WinUSB.inf that contains information required to install Winusb.sys as the device's function driver. You should not modify these directives.Note Because Windows XP doesn't provide WinUSB.inf, the file must either be copied to Windows XP systems by the co-installer, or you should provide a separate decorated section for Windows XP.

  • USB_Install.HW: This section is the key in the .inf file. It specifies the device interface globally unique identifier (GUID) for your device. The AddReg directive sets the specified interface GUID in a standard registry value. When Winusb.sys is loaded as the device's function driver, it reads the registry value DeviceInterfaceGUIDs key and uses the specified GUID to represent the device interface. You should replace the GUID in this example with one that you create specifically for your device. If the protocols for the device change, create a new device interface GUID.

    Note User-mode software must call SetupDiGetClassDevs to enumerate the registered device interfaces that are associated with one of the device interface classes specified under the DeviceInterfaceGUIDs key. SetupDiGetClassDevs returns the device handle for the device that the user-mode software must then pass to the WinUsb_Initialize routine to obtain a WinUSB handle for the device interface. For more info about these routines, see How to Access a USB Device by Using WinUSB Functions.

The following INF installs WinUSB as the OSR USB FX2 board's function driver on a x64-based system. The example shows INF with WDF coinstallers.

  • USB_Install.CoInstallers: This section, which includes the referenced AddReg and CopyFiles sections, contains data and instructions to install the WinUSB and KMDF co-installers and associate them with the device. Most USB devices can use these sections and directives without modification.

  • The x86-based and x64-based versions of Windows have separate co-installers.

    Note Each co-installer has free and checked versions. Use the free version to install WinUSB on free builds of Windows, including all retail versions. Use the checked version (with the '_chk' suffix) to install WinUSB on checked builds of Windows.

Each time Winusb.sys loads, it registers a device interface that has the device interface classes that are specified in the registry under the DeviceInterfaceGUIDs key.

Note If you use the redistributable WinUSB package for Windows XP or Windows Server 2003, make sure that you don't uninstall WinUSB in your uninstall packages. Other USB devices might be using WinUSB, so its binaries must remain in the shared folder.

How to create a driver package that installs Winusb.sys

To use WinUSB as the device's function driver, you create a driver package. The driver package must contain these files:

  • WinUSB co-installer (Winusbcoinstaller.dll)
  • KMDF co-installer (WdfcoinstallerXXX.dll)
  • An .inf file that installs Winusb.sys as the device's function driver. For more information, see Writing an .Inf File for WinUSB Installation.
  • A signed catalog file for the package. This file is required to install WinUSB on x64 versions of Windows starting with Vista.

Thesycon Usb Driver

Note Make sure that the driver package contents meet these requirements:

  • The KMDF and WinUSB co-installer files must be obtained from the same version of the Windows Driver Kit (WDK).
  • The co-installer files must be obtained from the latest version of the WDK, so that the driver supports all the latest Windows releases.
  • The contents of the driver package must be digitally signed with a Winqual release signature. For more info about how to create and test signed catalog files, see Kernel-Mode Code Signing Walkthrough on the Windows Dev Center - Hardware site.
  1. Download the Windows Driver Kit (WDK) and install it.

  2. Create a driver package folder on the machine that the USB device is connected to. For example, c:UsbDevice.

  3. Copy the WinUSB co-installer (WinusbcoinstallerX.dll) from the WinDDKBuildNumberredistwinusb folder to the driver package folder.

    The WinUSB co-installer (Winusbcoinstaller.dll) installs WinUSB on the target system, if necessary. The WDK includes three versions of the co-installer depending on the system architecture: x86-based, x64-based, and Itanium-based systems. They are all named WinusbcoinstallerX.dll and are located in the appropriate subdirectory in the WinDDKBuildNumberredistwinusb folder.

  4. Copy the KMDF co-installer (WdfcoinstallerXXX.dll) from the WinDDKBuildNumberredistwdf folder to the driver package folder.

    The KMDF co-installer (WdfcoinstallerXXX.dll) installs the correct version of KMDF on the target system, if necessary. The version of WinUSB co-installer must match the KMDF co-installer because KMDF-based client drivers, such as Winusb.sys, require the corresponding version of the KMDF framework to be installed properly on the system. For example, Winusbcoinstaller2.dll requires KMDF version 1.9, which is installed by Wdfcoinstaller01009.dll. The x86 and x64 versions of WdfcoinstallerXXX.dll are included with the WDK under the WinDDKBuildNumberredistwdf folder. The following table shows the WinUSB co-installer and the associated KMDF co-installer to use on the target system.

    Use this table to determine the WinUSB co-installer and the associated KMDF co-installer.

    WinUSB co-installerKMDF library versionKMDF co-installer
    Winusbcoinstaller.dllRequires KMDF version 1.5 or later

    Wdfcoinstaller01005.dll

    Wdfcoinstaller01007.dll

    Wdfcoinstaller01009.dll

    Winusbcoinstaller2.dllRequires KMDF version 1.9 or laterWdfcoinstaller01009.dll
    Winusbcoinstaller2.dllRequires KMDF version 1.11 or laterWdfCoInstaller01011.dll
  5. Write an .inf file that installs Winusb.sys as the function driver for the USB device.

  6. Create a signed catalog file for the package. This file is required to install WinUSB on x64 versions of Windows.

  7. Attach the USB device to your computer.

  8. Open Device Manager to install the driver. Follow the instructions on the Update Driver Software wizard and choose manual installation. You will need to provide the location of the driver package folder to complete the installation.
